- 捨棄式高速搪刀
- Nine9 99151 Boring Bars
- NIne9 99151 深孔搪刀4~ 6xD (加工深度4～6xD，動平衡良好)
容易操作
- 4 ～ 6xD加工深度，動平衡良好
經濟實惠
- 低成本，高效率，可取代端銑刀、搪孔刀
- 更換刀片可切削各種不同材種
應用
- 取代端銑刀，尤其是小孔徑搪孔
- 電子零件，精密零組件加工
 |
|---|
接桿
● 搪孔刀經濟型解決方案
| Order No. | Part No. | ØD | L |
|---|---|---|---|
| 99151A-04 | C20-ID04 | 4 | 49 |
| 99151A-06 | C20-ID06 | 6 | 52 |
| 99151A-08 | C20-ID08 | 8 | 49 |
| 99151A-10 | C20-ID10 | 10 | 42 |
| 99151A-11 | C20-ID11 | 11 | 21.5 |
| 99151A-15.5 | C20-ID15.5 | 15.5 | 21.5 |
鎢鋼刀桿 Ø5~Ø20
● 搪孔深度：L1 , 4～6xD
| Order No. | Part No. | ØD | Ød | Ød1 | L1 | L2 | L | 刀片/螺絲/板手 | Fig. |
|---|---|---|---|---|---|---|---|---|---|
| 99151-0500W | C06-0500-20L | 4.87~5.12 | 6 | - | 20.00 | - | 70 | CCGT030102 螺絲: NS-16030 板手:NK-T6 |
 |
| 99151-0525W | C06-0525-20L | 5.12~5.37 | 6 | - | 20.00 | - | 70 | ||
| 99151-0550W | C06-0550-22L | 5.37~5.62 | 6 | - | 22.00 | - | 70 | ||
| 99151-0575W | C06-0575-22L | 5.62~5.87 | 6 | - | 22.00 | - | 70 | ||
| 99151-0600W | C06-0600-24L | 5.87~6.12 | 6 | - | 24.00 | - | 70 | ||
| 99151-0625W | C06-0625-24L | 6.12~6.37 | 6 | - | 24.00 | - | 70 | ||
| 99151-0650W | C06-0650-26L | 6.37~6.62 | 6 | - | 26.00 | - | 70 | ||
| 99151-0675W | C06-0675-26L | 6.62~6.87 | 6 | - | 26.00 | - | 70 | ||
| 99151-0700W | C08-0700-28L | 6.87~7.12 | 8 | - | 28.00 | - | 85 | CCGT040102 螺絲: NS-20036 板手:NK-T6 |
 |
| 99151-0725W | C08-0725-28L | 7.12~7.37 | 8 | - | 28.00 | - | 85 | ||
| 99151-0750W | C08-0750-30L | 7.37~7.62 | 8 | - | 30.00 | - | 85 | ||
| 99151-0775W | C08-0775-30L | 7.62~7.87 | 8 | - | 30.00 | - | 85 | ||
| 99151-0800W | C08-0800-32L | 7.87~8.12 | 8 | - | 32.00 | - | 85 | ||
| 99151-0825W | C08-0825-32L | 8.12~8.37 | 8 | - | 32.00 | - | 85 | ||
| 99151-0850W | C08-0850-34L | 8.37~8.62 | 8 | - | 34.00 | - | 85 | ||
| 99151-0875W | C08-0875-34L | 8.62~8.87 | 8 | - | 34.00 | - | 85 | ||
| 99151-0900W | C10-0900-36L | 8.87~9.12 | 10 | - | 36.00 | - | 110 | CCGT060204 CCFT060204 螺絲: NS-25045 板手:NK-T7 |
 |
| 99151-0925W | C10-0925-36L | 9.12~9.37 | 10 | - | 36.00 | - | 110 | ||
| 99151-0950W | C10-0950-38L | 9.37~9.62 | 10 | - | 38.00 | - | 110 | ||
| 99151-0975W | C10-0975-38L | 9.62~9.87 | 10 | - | 38.00 | - | 110 | ||
| 99151-1000W | C10-1000-40L | 9.87~10.12 | 10 | - | 40.00 | - | 110 | ||
| 99151-1025W | C10-1025-40L | 10.12~10.37 | 10 | - | 40.00 | - | 110 | ||
| 99151-1050W | C10-1050-42L | 10.37~10.62 | 10 | - | 42.00 | - | 110 | ||
| 99151-1075W | C10-1075-42L | 10.62~10.87 | 10 | - | 42.00 | - | 110 | ||
| 99151-1100W | C10-1100-44L | 10.87~11.12 | 10 | - | 44.00 | - | 110 | ||
| 99151-1200W | C11-1200-150L | 11.87~12.12 | 11 | 11 | 70.00 | 20 | 150 | CCGT060204 CCFT060204 螺絲: NS-25045 板手:NK-T7 |
 |
| 99151-1300W | C11-1300-150L | 12.87~13.12 | 11 | - | 70.00 | - | 150 | ||
| 99151-1400W | C11-1400-150L | 13.87~14.12 | 11 | - | 70.00 | - | 150 | ||
| 99151-1500W | C15.5-1500-180L | 14.87~15.12 | 15.5 | 14 | 90.00 | 90 | 180 | ||
| 99151-1600W | C15.5-1600-180L | 15.87~16.12 | 15.5 | 15 | 90.00 | 90 | 180 | CCGT060204 CCFT060204 螺絲: NS-25060 板手:NK-T7 |
 |
| 99151-1700W | C15.5-1700-180L | 16.87~17.12 | 15.5 | - | 100.00 | - | 180 | ||
| 99151-1800W | C15.5-1800-180L | 17.87~18.12 | 15.5 | - | 100.00 | - | 180 | ||
| 99151-1900W | C15.5-1900-180L | 18.87~19.12 | 15.5 | - | 100.00 | - | 180 | ||
| 99151-2000W | C15.5-2000-180L | 19.87~20.12 | 15.5 | - | 100.00 | - | 180 |
捨棄式刀片CCG...
